Wavecom TnT Titan

Wavecom TnT Titan

Wavecom | SKU: WCMTNT-TITAN
In stock

IN STOCK

The Wavecom TNT Titan is a 5th-generation appliance tester with a 10A load capacity (20A optional), built for speed, accuracy, and compliance.

Supplied with a 4G Telstra tablet and the WinPATS Android App, it lets you test, record, and report directly from the palm of your hand. Powered by a lithium-ion battery, it delivers up to 3,000 test cycles per charge.

$1,427.80
$1,757.80 $1,427.80
(incl. GST)
19% OFF Contact Us to Order
Taxes included.
Load Capacity
FREE Australia-wide DeliveryFREE Express Shipping Money-Back Guarantee14-day Returns
Same Day DispatchSame Day Dispatch Lifetime Technical SupportLifetime Support
Have a question?Have a question? Call 1300 656 938 or email us

Overview

The TNT Titan sets a new benchmark in portable appliance testing.

Supplied with its own 4G Telstra tablet and preloaded with the WinPATS Android App, it gives you full control of your testing process from a mobile device. Using the app, you can record results, create reports, sync data to the cloud, and manage unlimited asset records, ensuring professional compliance at every stage.

For those who prefer simplicity, the tester itself supports one-button test procedures and can store up to 5,000 items in memory, while cloud integration removes storage limits altogether.

Built for serious test and tag operators, the TNT Titan also includes a rechargeable lithium-ion battery, enabling up to 3,000 test sets per charge, and is available in 10A or 20A configurations to suit different workplace requirements.

What's Included

  • Earth Lead with Alligator Clips (1800mm Black)
  • IEC Power Cable (10A units)
  • IEC 20/10 Power Cable with Circuit Breaker (20A Units)
  • 24 Month Conditional Warranty
  • Calibration Certificate
  • User Manual

Key Features

  • Lithium Ion Battery
  • In built Isolation Transformer
  • One Button Testing
  • 10A or 20A Operation
  • 8 inch 4G Android Telstra Tablet
  • WinPATS Android App
  • Bluetooth Low Energy Technology
  • Fully compliant to the AS/NZS3760:2010 standard

Specifications

Warranty: 2 years
Battery: Lithium Ion 4800 mAH 44WH
Bluetooth: In-Built Antenna 50m Range
Tablet: Telstra 8 Inch 800 x 1280 HD Screen
Leakage Current: 0 to 30.0mA at 200 to 265V
Voltage: 200 to 265VAC
Trip Current Test: 2 to 500mA in 1mA
Memory: 5000 Items Local Storage
Software: WinPATS App
View full details
Wavecom TnT Titan
$1,427.80
$1,757.80 $1,427.80
(incl. GST)
Wavecom TnT Titan
$1,427.80
$1,757.80 $1,427.80
(incl. GST)

Frequently Asked Questions

What makes the TNT Titan different from other Wavecom testers?

The TNT Titan comes with a 4G Telstra tablet and the WinPATS Android App, giving you full control, reporting, and cloud storage directly from your device.

Does the TNT Titan comply with AS/NZS 3760:2022?

Yes, the TNT Titan performs all tests required under the latest Australian standard, including Class I, Class II, leakage, and RCD testing.

How many tests can it perform on a single charge?

The internal lithium-ion battery delivers up to 3,000 test cycles per charge, making it suitable for high-volume or multi-site testing.

Can I store results on the tester itself?

Yes, the TNT Titan can store up to 5,000 items in memory, while cloud integration via the WinPATS App allows unlimited data storage.

Is the tester available in different versions?

Yes, the TNT Titan is available in a 10A model as standard, with a 20A upgrade option available at an additional cost.

Who is the TNT Titan best suited for?

It's ideal for contractors, businesses, and compliance managers who need a reliable, cloud-ready appliance tester with full reporting and mobile integration.
