Appliance Testing Supplies | SKU: Custom Test Tag: Light Duty CTLD34110
In stock

IN STOCK

$32.65
$32.65
% OFF Contact Us to Order
Taxes included.
Custom Test Tag
FREE Australia-wide DeliveryFREE AU-wide Delivery Money-Back Guarantee30-Day Returns
Same Day DispatchSame Day Dispatch Lifetime Technical SupportLifetime Support
Have a question?Have a question? Call 1300 656 938 or email us

What's Included

  • Metrel DeltaPAT MI 3309 BT
  • Soft Metrel Carry Case
  • Test & Tag Equipment Log Book
  • 100 x Heavy Duty Self-Laminating Tags
  • 50 x Failed Tags
  • 100 x RCD Test Tags
  • IEC Clover Adaptor
  • EasyOff Tag Remover
  • Metrel ES Manager Software
  • Permanent Marker Pen
  • 240V Extension Lead Adaptor
  • Mains & Test Lead
  • Probe & Earth clip
  • USB and RS232 cable

Also includes: User manual, Calibration certificate

Key Features

  • Battery or Mains Powered - excellent portability
  • Tests Portable & Fixed RCDs - no isolation transformer needed
  • Large LCD Display - with clear pass/fail indicator lights
  • Internal Memory - stores up to 1500 test results
  • Bluetooth Ready - connect to compatible Android apps and printers
  • USB & RS232 Export - transfer data to your PC for test report generation
  • Printer Compatible - works with the Godex Bluetooth Printer if you want to upgrade down the track

For more information read the full DeltaPAT 3309 BT review

Specifications

Warranty: 2 Years
Dimensions 14cm x 8cm x 23cm
Weight 1.2kg
Operation 10 h
Power Measurement Voltage: 230 V AC
Range: 0.00 kVA ÷ 4.00 kVA
RCD Testing 10mA, 15mA, 30mA
Touch Leakage Current Voltage: 230 V AC
Range: 0.00 mA ÷ 7.0 mA
Diff. Leakage Current Voltage: 230 V AC
Range: 0.00 mA ÷ 7.0 mA
Insulation Resistance Voltage: 250 VDC or 500 VDC
Range: 0.00-199.9 MΩ
Earth Continuity 200 mA in to 2.00 Ω
Range: 0.00-1999 Ω
Polarity Test <50 V AC
Voltage TRMS Range 80 ÷ 300 V
Overvoltage Category CAT II / 300 V
Protection Degree case IP 40/connectors IP 20

Download the full tech specification

View full details
Green
$32.65
$32.65
Green
$32.65
$32.65

Frequently Asked Questions

What tests can the Metrel DeltaPAT 3309 BT perform?

The DeltaPAT 3309 BT is a multifunctional appliance tester capable of conducting a comprehensive range of safety tests, including:

  • Visual inspection
  • Earth continuity resistance
  • Insulation resistance (250V and 500V)
  • Substitute leakage current
  • Differential and touch leakage current
  • IEC cord polarity test
  • RCD and PRCD testing (including PRCD-K and PRCD-S)
  • Power measurement
  • TRMS voltage measurement
  • Functional test

These capabilities ensure compliance with AS/NZS 3760 standards for electrical appliance safety testing.

Is the tester battery-powered or mains-powered?

The DeltaPAT 3309 BT operates on both battery and mains power.

It uses six AA NiMH or NiCd rechargeable batteries, providing approximately 8 hours of operation. This dual power option offers flexibility for both on-site and stationary testing scenarios.

Can this tester perform RCD testing without an isolation transformer?

Yes, the DeltaPAT 3309 BT features unique RCD testing technology that eliminates the need for an isolation transformer when testing portable RCDs. This simplifies the testing process and enhances safety.

Is the tester compatible with printers or barcode scanners?

The DeltaPAT 3309 BT includes USB and RS232 communication ports, allowing connection to compatible printers and barcode scanners.

Additionally, with an optional Bluetooth dongle, it can interface with Android devices for enhanced data management.

How many test results can be stored in the device?

The tester has an internal memory capable of storing approximately 1,500 test results.

These results can be exported to a PC using the included PATLink PRO software for reporting and record-keeping.
